Auth Module

The auth module provides Keycloak realm configuration management — export, clean, and import realm configs between Keycloak instances.

Workflow

┌──────────────────────────────────────────────────────────────────┐
│                    KEYCLOAK REALM SYNC                            │
├──────────────────────────────────────────────────────────────────┤
│                                                                   │
│  $ postkit auth export                                            │
│  ┌──────────────────┐     ┌──────────────────┐                    │
│  │ 1. Get admin     │     │ 2. Export realm   │                    │
│  │    token (API)   │────▶│    via REST API   │                    │
│  └──────────────────┘     └────────┬─────────┘                    │
│                                    │                              │
│                           ┌────────▼─────────┐                    │
│                           │ 3. Save raw to    │                    │
│                           │    .tmp-config/   │                    │
│                           └────────┬─────────┘                    │
│                                    │                              │
│                           ┌────────▼─────────┐                    │
│                           │ 4. Clean config   │                    │
│                           │    (strip IDs,    │                    │
│                           │    secrets, keys) │                    │
│                           └────────┬─────────┘                    │
│                                    │                              │
│                           ┌────────▼─────────┐                    │
│                           │ 5. Save cleaned   │                    │
│                           │    to realm-config│                    │
│                           └──────────────────┘                    │
│                                                                   │
│  $ postkit auth import                                            │
│  ┌──────────────────┐     ┌──────────────────┐                    │
│  │ 6. Read cleaned  │     │ 7. Import via     │                    │
│  │    realm config  │────▶│    keycloak-      │                    │
│  │                  │     │    config-cli     │                    │
│  └──────────────────┘     └──────────────────┘                    │
│                                                                   │
│  $ postkit auth sync   = export + import                          │
└──────────────────────────────────────────────────────────────────┘

Commands

Command	Description
export	Export realm from source Keycloak
import	Import realm config to target Keycloak
sync	Export from source then import to target

Prerequisites

• Docker — Required for postkit auth import (runs keycloak-config-cli)
• Network access to source and target Keycloak instances

Configuration

The auth module uses environment variables for Keycloak connections. See Auth Configuration for details.

What Gets Cleaned

The cleaning process removes sensitive and environment-specific data:

• IDs — All id and _id fields
• Container IDs — All containerId fields
• Users — Entire users array
• Client secrets — secret from all clients
• Key providers — org.keycloak.keys.KeyProvider components
• SMTP passwords — password from smtpServer
• IDP secrets — clientSecret from identity providers
• Storage credentials — bindCredential from storage providers
• Default role IDs — id from defaultRole
