Database Module
The db module provides a session-based database migration workflow for safe schema changes. Clone your remote database locally, develop and test changes, then deploy with confidence.
Workflow
┌─────────────────────────────────────────────────────────────────────────────┐
│ STREAMLINED MIGRATION FLOW │
├─────────────────────────────────────────────────────────────────────────────┤
│ │
│ $ postkit db start $ postkit db plan │
│ ┌──────────────────┐ ┌──────────────────┐ │
│ │ 1. Clone remote │ │ 3. Generate │ │
│ │ to local DB │ │ schema.sql │ │
│ │ 2. Start session │ │ 4. Run pgschema │ │
│ │ (track state) │ │ plan (diff) │ │
│ └────────┬─────────┘ │ 5. Save schema │ │
│ │ │ fingerprint │ │
│ ▼ └────────┬─────────┘ │
│ ┌──────────────────┐ │ │
│ │ User modifies │ ▼ │
│ │ schema files │ ┌──────────────────┐ │
│ │ (db/schema/*) │ │ Shows changes │ │
│ └──────────────────┘ │ to apply │ │
│ └──────────────────┘ │
│ $ postkit db apply │ │
│ ┌──────────────────┐ ▼ │
│ │ 6. Validate │ ┌──────────────────┐ │
│ │ fingerprint │ │ 7. Apply infra │ │
│ │ 7. Apply infra │ │ 8. Create dbmate │ │
│ │ 8. Create dbmate │ │ migration │ │
│ │ migration │ │ 9. Run dbmate │ │
│ │ 9. Run dbmate │ │ on local DB │ │
│ │ on local DB │ │ 10. Apply grants │ │
│ │ 10. Apply grants │ │ 11. Apply seeds │ │
│ │ 11. Apply seeds │ └────────┬─────────┘ │
│ └────────┬─────────┘ │ │
│ │ ▼ │
│ $ postkit db commit │
│ ┌──────────────────┐ ┌──────────────────┐ │
│ │ 12. Copy staging │ │ 13. Copy session │ │
│ │ migrations │ │ migrations │ │
│ │ 13. Update state │ │ to .postkit │ │
│ │ 14. Track for │ │ /db/migrations│ │
│ │ deploy │ │ 15. Update state │ │
│ └──────────────────┘ └──────────────────┘ │
│ │
│ $ postkit db deploy │
│ ┌──────────────────┐ ┌──────────────────┐ │
│ │ 15. Dry run on │ │ 16. Deploy to │ │
│ │ local clone │───────────►│ remote DB │ │
│ │ │ │ 17. Mark as │ │
│ │ │ │ deployed │ │
│ └──────────────────┘ └──────────────────┘ │
│ │
└─────────────────────────────────────────────────────────────────────────────┘
Commands
| Command | Description |
|---|---|
start | Clone remote DB to local, start session |
plan | Generate schema diff |
apply | Apply migration to local DB |
commit | Commit session migrations |
deploy | Deploy to remote database |
status | Show session state |
abort | Cancel session |
migration | Create manual migration |
remote | Manage remote databases |
infra | Manage infrastructure SQL |
grants | Manage grant statements |
seed | Manage seed data |
Important Notes
pgschema operates at the schema level only. Cluster and database level commands (like CREATE DATABASE, CREATE ROLE, CREATE EXTENSION) are not supported and must be handled through the infra/ directory or manual migrations.
See Plan Command Limitations for details.
Schema Directory Structure
Your schema files are organized into three categories:
1. Infrastructure (Handled Separately)
db/schema/infra/
├── 001_roles.sql # CREATE ROLE, CREATE USER (pre-migration)
├── 002_schemas.sql # CREATE SCHEMA (pre-migration)
└── 003_extensions.sql # CREATE EXTENSION (pre-migration)
Note: Files in infra/ are excluded from pgschema and applied separately.
2. Schema Objects (Processed by postkit db plan)
The plan command uses pgschema to process these directories:
db/schema/
├── types/ # Custom types
├── enums/ # ENUM types
├── tables/ # CREATE TABLE, ALTER TABLE
├── views/ # CREATE VIEW, CREATE MATERIALIZED VIEW
├── functions/ # CREATE FUNCTION
├── triggers/ # CREATE TRIGGER
├── indexes/ # CREATE INDEX
└── constraints/ # PRIMARY KEY, FOREIGN KEY, UNIQUE, CHECK
Supported: Tables, views, functions, triggers, indexes, constraints, enums, domains, sequences
3. Post-Migration (Handled Separately)
db/schema/
├── grants/ # GRANT statements (post-migration)
└── seeds/ # Seed data (post-migration)
Note: These are applied separately after the main migration.
Execution Order
- Pre-migration:
infra/(roles, schemas, extensions) - Migration: pgschema processes types → enums → tables → views → functions → triggers → indexes → constraints
- Post-migration:
grants/(permissions) →seeds/(data)
Prerequisites
- PostgreSQL client tools (
psql,pg_dump) - pgschema - Bundled with PostKit (no separate installation needed)
- dbmate - Auto-installed via npm (no separate installation needed)
Troubleshooting
See Troubleshooting for common issues and solutions.
